Bronze tubes round

Bronze tubes round



EN DIN
1982 1705 CuSn7Zn4Pb7





d

mm

D

mm

actual

size

weight

kg/m

15 25 14x26 3.50
15 30 14x31 5.50
15 35 14x36 7.90
15 40 14x41 10.60
15 45 14x46 13.70
18 36 17x37 7.80
20 28 19x29 3.60
20 30 19x31 4.40
20 32 19x33 5.30
20 35 19x36 6.60
20 40 19x41 9.50
20 45 19x46 12.50
20 50 19x51 15.90
20 55 19x56 20.50
20 60 19x61 23.90
20 70 18x71 33.00
24 35 23x36 5.60
25 32 24x33 3.80
25 40 24x41 8.00
25 45 24x46 11.10
25 55 24x56 18.30
25 60 24x61 22.40
25 65 24x66 26.90
30 36 29x37 4.00
30 38 29x39 5.00
30 40 29x41 6.20
30 45 29x46 9.30
30 50 29x51 12.60
30 55 29x56 16.40
30 60 29x61 20.50
30 65 29x66 25.40
30 70 29x71 30.40
30 80 29x81 41.10
30 90 28x92 53.80
30 100 28x102 70.00
35 42 34x43 5.20
35 45 34x46 7.00
35 50 34x51 10.50
35 55 34x56 14.30
35 60 34x61 18.40
35 65 34x66 22.90
35 70 34x71 28.20
35 80 34x81 51.10
35 90 34x91 6.50
40 50 39x51 7.90
40 55 39x56 11.70
40 60 39x61 15.90
40 65 39x66 20.40
40 70 39x71 25.80
40 80 39x81 36.50
40 90 41x91 49.60
40 100 38x102 62.80
40 110 38x112 77.10
40 120 38x124 94.00
45 56 44x57 9.70
45 60 44x61 13.00
45 65 43x67 17.50
45 70 44x71 22.90
45 75 44x76 28.10
45 80 44x81 34.10
50 60 49x61 9.80
50 65 49x66 14.30
50 70 49x71 19.80
50 75 49x76 24.90
50 80 49x81 30.40
50 90 49x91 42.60
50 100 49x101 56.10
50 110 49x111 71.00
50 120 49x121,5 88.20
50 130 48x131,5 104.70
55 65 54x66 10.70
55 70 54x71 16.20
55 75 54x76 30.90
55 80 54x81 26.30
60 70 59x71 12.30
60 72 59x73 14.40
60 75 59x76 16.50
60 80 59x81 23.10
60 85 59x86 28.90
60 90 59x91 35.20
60 100 59x101 48.70
60 110 59x111 63.60
60 120 59x121 80.70
60 130 59x131 98.50
60 140 59x141 117.70
64 76 63x77 15.20
65 80 64x81 19.80
65 85 64x86 24.00
65 90 64x91 31.20
70 82 69x83 16.50
70 85 69x86 18.50
70 90 69x91 26.30
70 95 69x96 33.50
70 100 69x101 39.90
70 110 69x111 54.80
70 120 69x121,5 71.90
70 130 69x131,5 89.70
70 150 68x152 129.20
75 90 74x91 21.40
75 95 74x96 28.00
75 105 74x106 35.20
75 120 73x122 66.80
80 90 78x92 17.70
80 95 79x96 22.70
80 100 79x101 29.60
80 110 79x111 44.60
80 115 78x117 55.30
80 120 79x121,5 61.70
80 130 79x131,5 79.50
80 140 79x141,5 98.70
85 100 83x102 26.60
85 105 84x106 31.30
85 115 83x117 47.60
85 125 83x127 64.70
90 100 88x102,5 19.50
90 110 89x111 32.90
90 120 89x121,5 50.10
90 130 89x131,5 67.90
90 140 89x141,5 87.00
90 150 88x152 107.50
90 170 88x172 159.90
95 115 93x117 35.30
100 110 98x112 22.90
100 115 98x117 28.60
100 120 99x121,5 37.10
100 130 99x131,5 55.66
100 140 99x141,5 74.00
100 150 98x152 94.50
100 160 98x162 116.20
100 190 98x192 191.00
100 200 98x202 218.00
110 120 108x122 25.00
110 130 109x131,5 40.50
110 140 109x141,5 59.60
110 150 108x152 80.00
110 160 108x162 101.90
110 170 108x172 125.50
110 190 108x192 176.40
120 140 1148x142 43.60
120 150 118x152 64.20
120 160 118x162 68.70
120 170 118x172 109.50
120 80 118x182 134.10
120 200 118x202 187.80
125 155 123x157 67.00
130 160 128x162 68.70
130 170 128x172 92.30
130 180 128x182 117.00
130 190 128x192 143.20
140 155 138x157 39.40
140 160 138x162 50.70
140 170 138x172 74.00
140 180 138x182 99.00
140 200 138x202 153.00
148 302 146x304 502.30
150 170 148x172 53.90
150 180 148x182 79.00
150 190 148x192 105.00
150 200 148x202 133.00
150 220 148x222 191.40
160 180 158x182 57.50
160 190 158x192 84.00
160 200 158x202 110.30
160 220 158x222 170.00
170 200 168x202 88.00
170 210 168x212 117.00
170 230 168x232 179.00
180 200 178x202 64.00
180 210 178x212 92.70
180 230 178x232 154.80
180 250 178x252 222.50
190 220 188x222 98.50
190 240 188x242 162.30
190 260 188x262 233.00
198 302 196x304 381.60
198 352 196x354 614.00
200 225 198x227 87.80
200 240 198x242 135.40
200 250 198x252 170.00
200 260 198x272 243.10
210 250 208x252 141.50
210 260 208x262 177.50
210 280 208x282 253.50
220 260 218x262 147.70
220 270 218x272 185.00
220 290 218x292 266.30
248 302 246x304 225.30
248 352 246x354 457.80
248 402 246x404 725.60
298 352 296x354 266.40
298 402 296x404 534.10
348 402 346x404 307.30

EN DIN
1982 1705 CuSn12





d

mm

D

mm

actual

size

weight

kg/m

15 35 14x36 7.90
15 40 14x41 10.60
20 32 19x33 5.30
20 40 19x41 9.50
20 45 19x46 12.50
20 50 19x51 15.90
20 60 19x61 23.90
20 70 18x71 33.00
24 35 23x36 5.60
25 45 24x46 11.10
25 55 24x56 18.30
30 38 29x39 5.00
30 45 29x46 9.30
30 50 29x51 12.60
30 55 29x56 16.40
30 60 29x61 20.50
30 65 29x66 25.40
30 70 29x71 30.40
30 80 29x81 41.10
30 90 28x92 53.80
35 42 34x43 5.20
35 50 34x1 10.50
35 60 34x61 18.40
35 70 34x71 28.20
35 90 34x91 6.50
40 50 39x51 7.90
40 55 39x56 11.70
40 60 39x61 15.90
40 70 39x71 25.80
40 90 41x91 49.60
40 120 38x124 94.00
45 56 44x57 9.70
46 60 44x61 13.00
50 60 49x61 9.80
50 65 49x66 14.30
50 70 49x71 19.80
50 75 49x76 24.90
50 80 49x81 30.40
50 90 49x91 42.60
50 100 49x101 56.10
50 110 49x111 71.00
50 120 49x121,5 88.20
60 70 59x71 12.30
60 80 59x81 23.10
60 85 59x86 28.90
60 90 59x91 35.20
60 100 59x101 48.70
60 110 59x111 63.60
60 120 59x121 80.70
65 85 64x86 24.00
70 100 69x101 39.90
75 90 74x91 21.40
75 95 74x96 28.00
80 100 79x101 29.60
80 120 79x121,5 61.70
80 130 79x131,5 79.50
80 140 79x141,5 98.70
85 105 84x106 31.30
90 140 89x141,5 87.00
100 200 98x202 218.00
120 150 118x152 64.20
120 170 118x172 109.50
120 200 118x202 187.80
130 150 128x152 47.10
130 180 128x182 117.00
140 160 138x162 50.70
140 200 138x202 153.00
148 302 146x304 502.30
150 180 148x182 79.00
150 200 148x202 133.00
160 220 158x222 170.00
170 200 168x202 88.00
170 210 168x212 117.00
170 230 168x232 179.00
180 250 178x252 222.50
190 240 188x242 162.30
198 302 196x304 381.60
198 352 196x354 614.00
220 270 218x272 185.00
248 302 246x304 225.30
248 352 246x354 457.80
298 402 296x404 534.10
